Drawings, Design & Planning

• Soil Test Report
• Site Survey
• Water Test Report
• Architectural Floor plans with Furniture layout (2D)
• Elevation Design (3D) (Based on final 2D floor plans)
• Structural Drawings (Based on final 2D and 3D drawings)
• Electrical Drawings (2D)
• Working Drawings (2D)

Structure

• Cement: Ramco /Coromandel/JSW or Equivalent
• Steel: FE 550D -ARS CRS (Corrosion Resistant)
• Concrete Grade: M25
• Foundation: Isolated footing upto 6' depth from NGL
• Ground Floor Height: Upto 3' height from NGL
• Parking Height: Upto 1' 6"height from NGL
• Ceiling Height: 10' height FFL to FFL
• Chamber Red bricks: 9" outer walls, 4.5" for inner walls
• M-Sand
• Internal Plastering: P-Sand
• External Plastering: P-Sand
• Parapet Wall: 4.5" brick work upto 3.5' height
• OHT: 2000 Ltrs (Sintex tank)

Super Details

• Waterproofing
• Termite Treatment
• Damp proof course
• Parapet Wall Coping
• Mesh Plastering
• Fibre reinforced plastering
• Waterproofing Additive for External Plastering
• AC points
• EV Charging Point
• Tile flooring with spacers
• Epoxy grouting in Bathrooms

Flooring

• Parking tiles
• Living, Dining, Bedrooms, Kitchen, Bathroom, Utility & Balcony: Vitrified Tiles
• Staircase: Granite
• Terrace: Screed Concreting with waterproofing

Kitchen

• Wall Tiles (Upto 2' above counter)
• Granite Counter Top
• Stainless Steel Sink with Drain Board
• Sink Faucet
• RO provision

Utility

• Washing machine provision
• Tap provision

Bathrooms & Plumbing

• Wall Tiles (Full Height)
• Floor mounted EWC, Wall mounted wash basin, Pillar tap, Shower set, Wall mixer, Health faucet, angle valves, stop valve, floor drains
• Brand: Parryware/Hindware
• CPVC pipes for all concealed & hot water lines
• PVC pipes for outer lines
• Brand: Astral or Equivalent

Doors & Windows

• Main Door: Teak Frame & Door (Polished finish)
• Internal Doors: Teak Frames, Wooden Skin Doors (Enamel paint finish)
• Bathroom Doors: WPC Frames, WPC Doors (Enamel paint finish)
• Windows: UPVC (white) Sliding with Clear Glass

Railings/Grills/Gates

• Staircase Railing: MS Railing (Enamel paint finish)
• Balcony Railing: SS Handrail with Glass (Toughened clear glass)
• Window Grills: MS Grills (Enamel paint finish)

Painting

• External: 1 coat white cement + 1 coat damp proof primer + 2 coats colour
• Brands: Asian Paints - Ace Or Birla Opus - Style
• Internal Walls & Ceiling: 1 coat putty + 1 coat primer + 2 coats colour
• Brands: Asian Paints - Tractor Or Birla Opus - Style Birla putty

Electrical

• Wires & Conduits: Orbit
• Switches: GM
• MCB: Anchor Roma
